Half suit 1550-1580

Composed of a breast, back, and pair of munions.

Breastplate: Black and white with a pronounced point below the center of the chest. Neck bordered by an inward turned, tapered, roped roll. Arm holes bordered by sliding gussets with inward turned, tapered, roped rolls. Waist flared for the fauld. Breast decorated with recessed polished bands, the overall surface rough from the hammer. There is an indistinct mark at the neck. Reblackened. There are buckles which appear to have been manufactured by being pierced from sheet at the shoulders. They attach to the inside of the gussets. This would suspend the breastplate and serve to return the gussets to the outward position. One missing its tongue and detatched.

Measurements: 13 in. from the center of the neck roll to the waist, 10 1/2 in. wide at the outside of the gussets when extended, 9 3/4 in. wide with the gussets compressed, 14 5/8 in. wide under the armholes, 13 7/8 in. wide at the waist.

Weight: 4 pounds 3.2 ounces (1905 g).

Gorget with munions: German. Unmarked, but most likely Nuremberg. Black with polished recessed bands at the borders. Decorated with two narrow recessed grooves at the center of the front, back and down the center of each shoulder. Collar formed of 3 plates front and back. The lower plate coming to a blunt point at the front and back. Outer edge with a recesed band with raised border. The upper plate with a pronounced plain inward turned roll. Hinged at the left with an integral hinge and secured by a pair of pins at the right. Shoulders of 7 plates. The second plate shaped over the point of the shoulder. The terminal plate with an iron buckle and mount to secure the strap around the arm. The collar plates are secured by three leathers front and back, each secured to the plates by two rivets in each plate. The shoulders have a row of sliding rivets at the back and two leathers (center and front). The rear of the spaulders is secured to the gorget by a short leather strap. Recessed bands lke these are normally associated with Nuremberg. Blackened surface of modern paint, all rivets, leathers and neck pins replaced.

Back plate: German. Black and white with recessed bands. Straight upper neck line for use with a deep collar, likely a pair of munions. Neck and arm holes bordered by narrow, inward turned, roped border. Three recessed white bands radiating from the waist and recessed bands at the neck and arm holes. Surface rough from the hammer and painted black. Bands polished bright. Single waist lame designed to carry a culet (missing). Marked at the neck with Nuremberg mark. There are pairs of small holes at the base of the rolls at the neck and arms which would have been used to secure a lining. These holes are normally associated with 17th c. wear, so this back was likely refitted for use after its initial manufacture and use.

Consisting of item number A-210 (breastplate), item number A-219 (munions) and item number A-268 (backplate).
